Site Recovery Job Wizard: Networks

On the Networks page of the Site Recovery Job Wizard you can map source VM virtual networks to appropriate target virtual networks and test networks.

Please proceed as follows:

1. Select Enable network mapping.

   Note
   A failover or a failback action needs to be on the actions list to allow enabling network mapping for your site recovery job.

2. The Network Mapping section opens. You have the following options:

   • Create a new network mapping:

     1. Click Create new mapping.

     2. The Add New Network Mapping dialog opens. Choose a source network, a target network and a test network, and click Save.



   • Add an existing network mapping:

     1. Click Add existing mapping.

     2. The Network Mappings dialog opens. Choose an appropriate network mapping and close the dialog box.



   • Edit an existing network mapping:

     1. Hover the pointer over the necessary item in the Network Mappings list and then click the Edit button to the right of the item.

     2. The Edit Network Mapping dialog box opens. Choose appropriate items from the Target network and the Test network lists and then click Save.



   • Delete an existing mapping: hover the pointer over the necessary item in the Network Mappings list and then click the Delete icon to the right of the item.



   • To leave the list of existing network mappings intact, go to the next page of the wizard.

3. Click Next to go to the next page of the wizard.
